WOOPTIX is an innovative Spain-based company that provides high-resolution, real-time phase measurement technology.
With its Wavefront Phase Imaging (WFPI) technology—overcoming the limitations of the traditional Shack-Hartmann method—WOOPTIX sets a new standard of resolution in the semiconductor, bio, and precision metrology markets.
Main Specification
| Items | Specification |
|---|---|
| Wavefront Resolution | 1000 x 1000 sampling |
| Wavelength | 400 - 700nm |
| Measurement Accuracy | < λ/100 RMS |
| Speed | Up to 180 fps |
| Interface | USB 3.0 or GigE |
| Measurement Range | Max. ±10 λ |
| Etc. | Offers higher dynamic range and enables 2D phase map generation compared to Shack-Hartmann sensors. |
